Why telcos must think beyond VoLTE roaming and consider VoLTE monitoring

Michael Wallbaum

About Voipfuture

Voipfuture is a voice over IP service monitoring and analytics company, offering the only carrier-grade dual-visibility platform on the market.

With the planned shutdown of 2G and 3G networks, the telco industry has a strong motivation to focus on Voice over LTE (VoLTE) services and the extension of its use to inbound and outbound international roamers. But why?

Because with VoLTE roaming, users can make voice calls over the 4G LTE network wherever they happen to be. VoLTE roaming extends IP Multimedia Subsystem (IMS) applications in a way that enables users to access voice services outside their home network. How the various networks work together to ensure seamless IMS services regardless of a geographic location is defined by VoLTE peering and interconnecting.

Guidelines related to standardized VoLTE roaming, interconnection, and interworking are outlined in document IR.65 from the GSMA (Global System for Mobile Communications Association). It details three reference architectures for IMS roaming, two of which rely on local breakout (LBO): LBO Home Routing (LBO-HR) and LBO Visitor Routing (LBO-VR), and a third known as S8 Home Routing (S8HR).

By providing IMS functionality through the Home Public Mobile Network (HPMN) instead of the Visited Public Mobile Network (VPMN), S8HR simplifies the roaming interface, making it the most straightforward architecture to implement. Its name is derived from the S8 standard reference interface utilized between the Serving Gateway (SGW) and the Packet Data Network Gateway (PGW).

The S8HR approach to VoLTE roaming clearly won the race, yet the architecture itself brings certain challenges that Mobile Network Operators (MNOs) need to overcome. However, recent developments mean VoLTE roaming will soon no longer be a bonus, but a critical feature of mobile networks.

Why VoLTE roaming?

The rise of 5G means existing 2G and 3G networks are being shut down with plans to reassign spectrum to new, more-modern services. For this to happen, the telco industry needs to find alternatives to remaining legacy 2G/3G services, including circuit-switched voice calls.

VoLTE and VoLTE roaming services are the alternatives. The adoption of VoLTE as a replacement to legacy voice services will allow us to retire out-of-date network equipment and improve network efficiency, utilizing the spectrum for new 5G applications.

While the first commercial VoLTE service was launched in the US in 2012, it is only recently that we have seen a significant shift towards mobile voice services utilizing the LTE network. A GSMA report from July 2021 found that so far there have been 717 LTE launches around the world. However, when it comes to VoLTE there is a notable drop off, with only 232 market launches and roughly 50 VoLTE roaming deployments.

However, the market is there, and Ericsson estimates the number of subscriptions that include VoLTE-enabled services by the end of 2027 will be almost 7 billion, nearly 90% of all 4G and 5G subscriptions:

With a proper replacement for legacy voice services, operators and regulators can move forward with the long due shutdown of 2G and 3G networks. But how do we ensure a smooth transition to VoLTE roaming? What challenges is the industry facing?

The challenge of widespread VoLTE roaming adoption

The main challenge preventing a fast rollout of VoLTE roaming is the extensive and costly testing required. Operators could send SIM cards for partner testing when working with 2G and 3G voice services, often incorporating phone simulators as well.

In contrast, VoLTE means operators must exchange the devices their users take with them while roaming to ensure they are compatible with the configuration of partner networks.

A report from October 2020 found 2,983 devices supporting VoLTE architecture. Given that this number will now be even higher, you can see why operators haven’t yet implemented comprehensive VoLTE roaming services. Every device on the market needs testing, creating a complicated and lengthy process and incurring significant costs.

However, with decommissioning of the 2G and 3G networks underway, the need for VoLTE now outweighs any testing issues.

VoLTE roaming: business drivers

Beyond the fact that VoLTE allows operators to migrate legacy circuit-switched voice services to an IP-centric network, it offers a range of other benefits, such as:

  • Better voice Quality—With VoLTE, service providers can deliver voice calls across a wider frequency range. Using codecs such as EVS (Enhanced Voice Services) means customers can now make international calls using high definition voice.
  • Shorter call setups—Previous circuit-switched voice calls had a significant delay between call initiation and the initial transfer of audio. VoLTE reduces the call setup time to roughly a third of legacy systems.
  • Multimedia support—Now, users can combine high-definition voice with video calls.

All these VoLTE benefits translate to roaming, so users can access improved services whether they are at home or traveling. Plus, VoLTE roaming now ensures better coverage thanks to new operators launching 4G-only services and the reduced network congestion present when using 4G LTE technology.

This is critical due to the significant revenue derived from roaming voice calls. Research shows the global roaming market was valued at $70.76 billion in 2020, a slight dip from previous years caused by the pandemic. Keep in mind, however, that it is predicted to grow with a compound annual growth rate of 5.1% to over $100 billion by 2028.

Roaming voice calls are a significant offering that operators need to maintain in parallel to the process of shutting down their 2G and 3G networks.

What does it take to deploy S8HR roaming? Are you ready for it?

With LBO options now seen as obsolete, VoLTE roaming deployments are based on the S8HR architecture. This can pose various technical issues described in GSMA’s VoLTE implementation guide.

IMS issues

Implementing S8HR has been known to produce IMS issues related to:

  • Enabling and disabling IMS-APN (Access Point Name) while roaming
  • IMS registration
  • Identifying locations and time zones
  • Compatibility between IPv4 and IPv6
  • Handling SRVCC (Single Radio Voice Call Continuity)

S8HR VoLTE roaming also impacts the Quality of Service (QoS) parameters exchanged between the HPMN and VPMN. GSMA has defined the minimum set of QoS parameters that should be supported by the S8HR architecture.


VoLTE roaming requires SMS over IP (SMSoIP) service, and there would typically be an agreement in place between HPMN and VPMN providers.

Emergency calling

Emergency calls must be handled and terminated by the VPMN. This is broadcasted to the roaming device to determine if it is possible to make a VoLTE call or if legacy circuit-switched technology is required.

Regulatory concerns

As regulations (e.g., legal intercept, data retention, etc.) vary from country to country, operators must enforce rules based on the requirements of the VPMN. This holds true even though S8HR VoLTE roaming restricts IMS to the HPMN.


Operators have reported several issues during VoLTE roaming testing, such as:

  • Original Equipment Manufacturer (OEM) blocking VoLTE/VoLTE roaming
  • Variations due to device settings
  • Shipping devices to different locations to test VoLTE roaming networks
  • The cost associated with testing a large number of VoLTE-enabled devices, as described above

Proactive monitoring: the key to delivering optimal VoLTE roaming services

With new VoLTE networks and the interworking of multiple networks for VoLTE roaming, operators need to understand the new requirements on monitoring tools and the data they produce. Guaranteeing quality VoLTE roaming services requires proactive monitoring and the ability to gather data per foreign network.

Conventional VoLTE monitoring needs tools that are capable of capturing data on both the control plane (call signaling performance) and the user plane (in-call media quality). Without information on a call level, operators cannot effectively troubleshoot problems or gather meaningful statistics for quality monitoring and automatic triggers.

This involves the utilization of associated KPIs such as the Internet Engineering Task Force’s (IETF’s) RFC 6076 KPIs for signaling monitoring and TR 103639 KPIs from the European Telecommunications Standards Institute (ETSI) for media monitoring. With ETSI’s time-slicing KPIs, operators can gain real-time visibility and understand how the quality of a call changes across its duration.

However, VoLTE Roaming Monitoring is not the same as VoLTE Monitoring and it adds some specific challenges related to guaranteeing a quality service while utilizing a foreign network. These include:

  • Delivering the same coverage and in-call voice quality to prevent the use of over-the-top services
  • Ensuring high-quality SMS services while roaming
  • Tracking service performance data individually for each specific roaming partner

These key differences must be addressed when planning a VoLTE roaming monitoring solution. Ensuring crystal-clear voice connections requires real-time visibility of the traffic and the ability to produce insights into the performance of each roaming partner.

Monitoring VoLTE roaming with Voipfuture’s Qrystal solution

All of these requirements are addressed by Voipfuture’s Qrystal solution to ensure operators get all the data they need to monitor VoLTE roaming services.

To monitor VoLTE roaming services standard Qrystal Probes are deployed at the home network’s S8HR interface. They analyze all traffic and prepare quality summaries which are sent to the central Qrystal Manager. The Manager aggregates information to create actionable insights, alarms and reports. With Qrystal, you get a complete end-to-end view to ensure crystal-clear communication while your subscribers are roaming.

Image of Qrystal’s VoLTE roaming architecture

This includes data on:

  • Voice service performance data on signaling and media transport for each roaming partner
  • Data on SMS delivery and performance per roaming partner
  • Statistics and detailed root cause analytics to get to the bottom of any issues behind poor-quality calls, call drops, one-way audio, etc.

Qrystal’s ability to provide all this data separately for each visited network – as opposed to collectively for all roamers – is key to the successful operation of VoLTE roaming.

A final word before we part

With the impending shutdown of 2G and 3G networks around the world, VoLTE offers an entirely IP-centric alternative to legacy circuit-switched calls. While challenges remain to guarantee widespread adoption, spurred on by the growing business case, operators have finally begun to make strides toward VoLTE and VoLTE roaming.

Given the new technology, operators need new tools to monitor VoLTE services, particularly the interworking of networks during roaming. Voipfuture’s Qrystal solution offers all the necessary functionality to understand the relationship between the visited and home network, provide high-quality call data, and deliver optimal services.
